NA-1600D

1600W Max @ 1-Ohm Class-D 1-Channel Car Amplifier

RMS / MAX @ 4-Ohm: 300W/600W
RMS / MAX @ 2-Ohm: 500W/1000W
RMS / MAX @ 1-Ohm: 800W/ 1600W
Input Level: 0.2V–5V
Frequency Response: 15Hz–250Hz
LPF: 50Hz–250Hz
Subsonic Filter: 10Hz–50Hz
Bass Boost Frequency: 40Hz–100Hz
Bass Boost Level: 0-15dB
THD at 4-Ohm load 30% Rated Power: <0.2% Signal to Noise Ratio: >80dB
Best Efficiency: >85%
Minimum Load: 1-Ohm
Dimensions: 231x121x44mm
